Import of manufacturer’s data into equipment database in Microsoft Excel® formatĭisplay equipment information on components
Standard CAD drawing facilities and dimensioning capabilitiesĮxport in Enhanced Metafile Format and picture files (JPG, BMP, PNG, TIF, GIF, PCX)Įxport formats for Weidmüller and other label printers Working on multiple projects simultaneously Importing of images (JPG, BMP, PNG, TIF, GIF, PCX and PDF)Ĭopying of symbol groups between projects Graphical cable definition – including user defined symbolsīi-directional compatibility with other CAD systems (DWG, DXF, DXB, DWF and XPS (DWFx)) Locking of component names, terminals, and wire labels Real time connection and open contacts check up Real-time component numbering, generation of cable names and terminal numbers, and cross referencing Multiple symbol libraries (including IEC) with graphical overview, grouping and searchingĬreation of custom symbols and drawing macros Real-time lists for: components, terminals, parts, contacts, cables, cable cores, wires, PLC I/Os, documentsįiltering/sorting into lists + storing the filter or sorting
